| TUNING |
|---|
| Type | DSP Tuner |
| Memory Presets | 10 (5 FM, 5 AM / MW) |
| Rotary Tuning | V |
| Display |
|---|
| LCD / VFD / Dial Scale | LCD |
| View Area (mm / inch) | 56 x 23 / 2.2 x 0.91 |
| Graphic / Character Type | Segment |
| Back Light | V |
| Feature |
|---|
| Charger | V |
| TUNER |
|---|
| FM - Frequency (MHz) | 87.5 - 108 |
| AM / MW - Frequency (kHz) | 522 - 1710 (9K) , 520 - 1710 (10K) |
| MEDIA |
|---|
| Aux - in | V |
| Audio |
|---|
| EQ - Loudness on/off | V |
| OUTPUT DEVICES |
|---|
| Speaker - Size ( mm / inch ) | 5 inches |
| Speaker - Impedance | 8 ohms |
| Speaker - Magnetically Shield | V |
| OUTPUT POWER (TYPICAL) |
|---|
| AC / DC / AC to AC in (Speaker) | 5W ( AC ) |
| Batteries (Speaker) | 2W (DC) |
| POWER SUPPLY |
|---|
| AC - USA | 120V 60 Hz |
| AC - EUR | 230V 50 Hz |
| Batteries (Main Power) | 4 x 1.5V (UM - 2) |
| I/O SOCKET |
|---|
| Aux - in | V |
| Dimensions |
|---|
| Width (mm/inch) | 324 / 12.76 |
| Height (mm/inch) | 232.5 / 9.15 |
| Depth (mm/inch) | 193.5 / 7.62 |
| Weight (g & lb. oz) | 3000 / 6lb. 9.8oz |
| PARTICULAR PERFORMANCE |
|---|
| 1 | WATER RESISTANCE JIS - 4 |
