| TUNING |
|---|
| Type | PLL synthesized |
| Memory Presets | 10 (5 FM, 5 AM / MW) |
| Rotary Tuning | V |
| Auto Tuning System | V |
| Display |
|---|
| LCD / VFD / Dial Scale | LCD |
| View Area (mm / inch) | 99.6 x 24.6 / 3.92 x 0.97 |
| Graphic / Character Type | Segment |
| Back Light | V |
| TUNER |
|---|
| FM - Frequency (MHz) | 87.5 - 108 |
| AM / MW - Frequency (kHz) | 520 - 1710 (10k), 522 - 1629 (9k) |
| AM / MW - Adjustable Tuning Step | V |
| MEDIA |
|---|
| Aux - in | V |
| Clock |
|---|
| Real Time | V |
| Radio Alarm | V |
| Buzzer Alarm | HWS |
| Snooze | V |
| Sleep | V |
| Audio |
|---|
| EQ - Tone Control | V (Rotary) |
| OUTPUT DEVICES |
|---|
| Speaker - Size ( mm / inch ) | 6 1/2 inches |
| Speaker - Impedance | 8 ohms |
| OUTPUT POWER (TYPICAL) |
|---|
| AC / DC / AC to AC in (Speaker) | 7W (AC / DC) |
| Batteries (Speaker) | 4.5W |
| Earphones | 5 + 5 mW (monaural) |
| POWER SUPPLY |
|---|
| AC - USA | 120V 60 Hz |
| AC - EUR | 230V 50 Hz |
| DC in | 9 - 14V DC 1A |
| Batteries (Main Power) | 6 x 1.5V (UM - 1) |
| I/O SOCKET |
|---|
| DC in | V |
| Earphones | V |
| Aux - in | V |
| DC Output | 5V / 0.5A |
| Dimensions |
|---|
| Width (mm/inch) | 262 / 10.31 |
| Height (mm/inch) | 382 / 15.04 |
| Depth (mm/inch) | 271 / 10.67 |
| Weight (g & lb. oz) | 4244 / 9lb. 5.7oz |
| PARTICULAR PERFORMANCE |
|---|
| 1 | Deep Bass Compensation |
| 2 | WATER RESISTANCE JIS - 4 |
