| TUNER |
|---|
| FM - Frequency (MHz) | 87.5 - 108 for the common area (default) / 76 - 90 for Japan / 64-108 for Eastern European countries and Russia / 76-108 for some of China area and European countries |
| FM - RDS / RBDS | PS / PTY / RT / CT |
| MW - Frequency (kHz) | 522 - 1710 (9k) / 520 - 1710 (10k) |
| MW - Adjustable Tuning Step | V |
| Type | DSP tuner |
| Preset | 10 (5 FM and 5 AM / MW) |
| MEDIA |
|---|
| USB | V |
| Aux - in | V |
| Others | Bluetooth wireless audio |
| AUDIO DECORDES |
|---|
| CD / SD / USB | MP3/WMA |
| Clock |
|---|
| Real time - Radio Control - DAB / RDS | V |
| Alarm | (2 Alarms) Tuner / Media / Buzzer |
| Sleep | V |
| Nap | V |
| Snooze | V |
| Display |
|---|
| LCD / VFD | LCD (ABN type) |
| View Area (mm / inch) | 44 x 84 / 1.73 x 3.31 |
| Graphic / Character Type | Segment |
| Back Light | V |
| Dimmer | Automatic and adjustable |
| Feature |
|---|
| Bluetooth | V2.1 class-II (A2DP+AVRCP) |
| Audio |
|---|
| EQ - Treble / Bass Control | V |
| EQ - Loudness on/off | V |
| Amplifier |
|---|
| Speaker Output (TYP.) | 7W |
| Earphones Output | 1+1mW (32 ohm) |
| SPEAKER |
|---|
| Size ( mm / inch ) | 3 INCHES |
| Impedance | 8 OHM |
| Magnetically Shield | V |
| I/O SOCKET |
|---|
| AC / DC - in | AC / DC - in |
| Aux - in | V |
| DC in | V |
| USB | V |
| Ext.Antenna | FM F terminal+ AM ANT-IN(USA) |
| Others | Subwoofer out |
| POWER SUPPLY |
|---|
| AC | V |
| DC in | V |
| Accessories |
|---|
| AC Cord | V |
| Remote Control | V |
| FM Wiring Antenna | V |
| Dimensions |
|---|
| Width (mm/inch) | 240 / 9.45 |
| Height (mm/inch) | 112 / 4.41 |
| Depth (mm/inch) | 193.4 / 7.61 |
| Weight (g & lb. oz) | 2900 / 6lb. 6.3oz |
| PARTICULAR PERFORMANCE |
|---|
| 1 | * Deep Bass Compensation |
| 2 | * Deep Bass Compensation |
