| TUNING |
|---|
| Type | DSP Tuner |
| Memory Presets | 20 (10 FM and 10 AM / MW) |
| Display |
|---|
| LCD / VFD / Dial Scale | LCD |
| View Area (mm / inch) | 42.2 x 23.2 / 1.66 x 0.91 |
| Graphic / Character Type | Segment |
| Back Light | V |
| Feature |
|---|
| Stereo | Earphones / Speaker |
| TUNER |
|---|
| FM - Frequency (MHz) | 87.5 - 108 for the common area (default) / 76 - 90 for Japan / 64-108 for Eastern European countries and Russia / 76-108 for some of China area and European countries |
| AM / MW - Frequency (kHz) | 522 - 1710 (9k) / 520 - 1710 (10k) |
| AM / MW - Adjustable Tuning Step | V |
| MEDIA |
|---|
| Aux - in | V |
| Clock |
|---|
| Real Time | V |
| Radio Alarm | HWS |
| Buzzer Alarm | HWS |
| Adjustable Alarm Level | Radio Alarm/Buzzer Alarm |
| Snooze | V |
| Sleep | V |
| OUTPUT DEVICES |
|---|
| Speaker - Size ( mm / inch ) | 2.25 inches |
| Speaker - Impedance | 4 ohm |
| OUTPUT POWER (TYPICAL) |
|---|
| AC / DC / AC to AC in (Speaker) | 0.7W+0.7W |
| Batteries (Speaker) | 0.7W+0.7W |
| Earphones | 1.5mW+1.5mW |
| POWER SUPPLY |
|---|
| DC in | 6V DC 1A |
| Batteries (Main Power) | 4x 1.5V (UM - 3) |
| I/O SOCKET |
|---|
| DC in | V |
| Earphones | V |
| Aux - in | V |
| Dimensions |
|---|
| Width (mm/inch) | 196.5 / 7.74 |
| Height (mm/inch) | 108 / 4.25 |
| Depth (mm/inch) | 40.5 / 1.59 |
| Weight (g & lb. oz) | 475.8 / 1lb. 0.8oz |
